Plain weave,Black & Red Spray Paint Heavy Duty Crimped wire mesh/Crusher (Vibrating) screen mesh for Quarry Ming
1. Heavy duty Crimped wire mesh is customization manufactured for products and applications requiring strength and rigidity, such as sieves and vibration filter media for sizing, sorting and filtering heavy or large materials. Heavy duty wire cloth is used in the mining, refining and construction industries.
Pre-crimp wire cloth and heavy duty mesh are manufactured in large wire diameters. and its most common weaving method is plain weaving.We offer a wide range of metals and alloys for use in the mesh to meet product requirements. AExtra-wide roll widths are available.
2. * Basic Specification
Name | vibrating screen wire mesh/heavy duty crimped wire mesh |
Material | High Carbon steel:65Mn,45#,50#,55#,60#,70#,,72A Stainless steel wire:SUS304,304L,316,316L etc Aluminum wire:5154,5050,5056,6061,6063 etc Galvanized low carnon steel |
Wire diameter | 0.8mm-12.7mm,Our finished wire is inspected by third party SGS,Tolerance+_0.03mm . |
Aperture/Opening | 2mm to 100mm,tolerance +-3% |
| Surface treatment | spray paint, oil painting, eltro or hot-dip galvanized,pvc-coated |
*Chemical composition for Carbon steel & Stainless Steel
| Carbon steel composition and weaved wire diameter reference | |||||
| No. | Grade | Chemical Composition | Wire diameter | ||
| C | Si | Mn | mm | ||
| 1 | 45 | 0.42-0.50 | 0.17-0.37 | 0.50-0.80 | 2.0-6.0 |
| 2 | 50 | 0.47-0.55 | 0.17-0.37 | ||
| 3 | 55 | 0.52-0.60 | 0.17-0.37 | ||
| 4 | 60 | 0.57-0.65 | 0.17-0.37 | ||
| 5 | 65 | 0.62-0.70 | 0.17-0.37 | ||
| 6 | 70 | 0.67-0.75 | 0.17-0.37 | ||
| 7 | 65Mn | 0.62-0.70 | 0.17-0.37 | 0.90-1.20 | 2.0-14.0 |
| 8 | 72A | 0.70-0.75 | 0.15-0.35 | 0.30-0.60 | 2.0-22.0 |
Common Stainless steel wire chemical composition
3. Part Speciification for your refereence
SPECIFICATION:We provide the attached specification,but it does not
limited to them.
It can be as client's instruction.
| Tensile strength for different wire diameter | |||||
WIREDIA(MM) | TENSILE STRENGTH(MPA) | RA | WIRE DIA(MM) | TENSILE STRENGTH(MPA) | RA |
2 | 1450-1700 | 45% | 7 | 1350-1550 | 45% |
3 | 1450-1700 | 45% | 8 | 1350-1550 | 40% |
3.5 | 1450-1700 | 45% | 9 | 1150-1300 | 40% |
4 | 1450-1700 | 45% | 10 | 1100-1250 | 40% |
4.5 | 1450-1700 | 45% | 11 | 1100-1250 | 40% |
4.9 | 1450-1650 | 45% | 12 | 1100-1250 | 40% |
5 | 1450-1650 | 45% | 12.5 | 1050-1150 | 40% |
6 | 1400-1600 | 45% | 13 | 1050-1150 | 40% |
| Item | Wire diameter Mm | Open size Mm | Width M | Length M | Weight Kg |
| 1 | 2 | 3 | 1.5 | 2 | 32 |
| 2 | 3 | 5 | 1.5 | 2 | 42.6 |
| 3 | 4 | 8 | 1.5 | 2 | 51.13 |
| 4 | 4.5 | 12 | 1.5 | 2 | 46.77 |
| 5 | 5 | 16 | 1.5 | 2 | 45.52 |
| 6 | 5.5 | 18 | 1.5 | 2 | 49.37 |
| 7 | 6 | 20 | 1.5 | 2 | 52.7 |
| 8 | 6 | 22 | 1.5 | 2 | 48.96 |
| 9 | 6.5 | 24 | 1.5 | 2 | 52.87 |
| 10 | 6.5 | 27 | 1.5 | 2 | 48.12 |
| 11 | 7 | 30 | 1.5 | 2 | 50.63 |
| 12 | 8 | 50 | 1.5 | 2 | 42.29 |
| 13 | 12 | 75 | 1.5 | 2 | 64 |
5. 9 TYPES OF Different edge treatments
We can satify your various requestment on the edge, they can be with hook and sheath, also can be in flat sheet without hook and sheath. for hook & sheath also include 9 types
4. Production process
5. Common packing show
|
|
