Rectangle SS/Monel/Inconel /PPKNITTED wire mesh demister pad with iron/SS/PP 25*3/4/6mm frame used in separation tank

Knitted wire mesh demister pad is also known as mist eliminator or sprays. Knitted wire mesh demister pad is supplied in standard, high efficiency and high permeability. Demister Pads are essentially porous blankets of carefully knitted wire mesh designed and constructed to efficiently abate mist particles. Demister pad is mainly used to eliminate streams with diameter of more than 3μm to 5μm.

Knitted wire-mesh demister(or mist eliminator)is mainly used to separate drops of the diameter between 3μm to 5μm, the operating principle is showed in the fig at the right side. When the gas with liquid drops rises at a certain speed, passing through the wire mesh on the grid bar, the inertia of the rising drops make them collide with the wire and then adhere to the surface of the wire. The drops on the wire will diffuse and subside. It makes the drops form bigger ones and then flow along the wire to the intertexture of the wire. Because the wire can be humidified, and because of the surface tension of liquid and the capillarity effect of the wire, the drops will become bigger and bigger. They will be separated and fall when their own weight exceed the resultant force of buoyancy of the rising gas and surface tension of liquid. They will flow to the device of the container in the backward position. As long as the speed of the gas is properly controlled and with other proper condition, the efficiency of foam remove will be as high as 97% after the gas pass through wire-mesh demister. The purpose of removing foam will be achieved completely.

Features: Simple structure, light, less pressure drop, big surface, high demisting efficiency, easy installation, operation and maintenance and long service life.

Material:Stainless steel 304,304L,316....etc

Styles

(1) Standard

28 layers of knitted mesh for 100mm thick

(2) High Efficiency

32 layers of knitted mesh for 100mm thick

(3)High Penetration

28 layers of knitted mesh for 100mm thick

Four main types technical parameters

Anping Blue Star Metal Wire Mesh Products Co., Ltd was founded in 2002 and it originated from Blue Star Wire Mesh Factory which started since the year 1992. It is located in eastern industrial zone of Anping County, Hebei of China, with a land area of 7600 square meters, workshop of 4000 square meters and a staff of 82 people. Blue Star is known in the trade with its good quality, reasonable price and timely delivery.

Our main products include knitted wire mesh, wire mesh demister,stainiless steel woven wire mesh, etc. These products find extensive uses in petroleum, chemical industry, pharmacy, chemical fiber, paper-making, electronics, construction, aerospace and other fields.
