    250 - 635 Mesh Stainless Steel Wire Cloth , Woven Metal Mesh Anti - Corrosion

    Ask Lasest Price
    Brand Name : BS•EVER
    Model Number : Stainless Steel Twill Weave Wire Mesh
    Certification : ISO 9001:2015
    Price : Negotiable
    Payment Terms : T/T, L/C, Western Union, MoneyGram
    Supply Ability : 300 Sq.m/ Day
    Delivery Time : According to the Quantity Ordered
    • Product Details
    • Company Profile

    250 - 635 Mesh Stainless Steel Wire Cloth , Woven Metal Mesh Anti - Corrosion

    Bright Raw Edge Stainless Steel Twill Weave Wire Mesh With Mesh 250 - 635 for Filter


    The stainless steel wire mesh can be divided into four kinds according to the weaving method,stainless steel plain weave wire mesh, stainless steel twill weave wire mesh,stainless steel plain dutch weave wire mesh, stainless steel twill dutch weave wire mesh.


    “Twilled weave” is a weave type in which the warp wires and shute wires pass over two and under two in both directions. This is different from a plain weave, which is when the wires are woven one over and one under. As a result, “twilled weave” is often more pliable than a comparable plain weave wire mesh specification. By and large, twilled weave is often used in filtration applications. The images below illustrate twilled weave, but because twilled weave is usually reserved for fine mesh, identifying a twilled weave usually requires a mesh counter.


    Twilled Weave w/ Two End Views

    Applications
    Sizing (screening), separation (filtering), refining, drying, reinforcement, catalysts, conveyors, shielding, and other industrial, mining and agricultural applications

    Material:

    Stainless steel 201/304/304L/316/316L/310S/321/317L/410S/431/904L, pure nickel, Monel metal, titanium, copper, brass, aluminum alloys,etc.

    Twilled Weave (250 to 635 mesh)

    MeshWire DiameterOpening
    mm
    Open Area %Mass (Weight)
    kg/m2 stainless steel wire cloth
    SWGmm
    250480.040.06235.80.212
    300480.040.04526.80.254
    32548・1/20.0350.04330.50.210
    350490.030.04233.60.167
    400490.030.03427.80.180
    500500.0250.02625.80.160
    6350.0200.02025.00.130
